Description

ShineRetrofits Input:
Barron Lighting’s NHBL Series LED Highbay Light is made for demanding spaces. It has a strong aluminum body and a lens that resists impact and heat. You can switch between different brightness levels and color temperatures to fit your needs. It is NSF certified, water-resistant, and perfect for food, industrial, or outdoor use.

Features:
• Robust die-cast aluminum housing in a white finish
• IK10 Rated polycarbonate lens
• IK07 Rated glass lens accessory available
• Built in receptacle on the front panel for easy plug and play senso
installation
• 6’ Three conductor whip for building power supply
• 6’ Four conductor whip for 0-10V dimming wires and emergency input
• Comes standard with 6’ aircraft mounting cable
• Polycarbonate lens (IK10 Rated) offered with an optical lens providing a 90°
distribution
• Glass lens (IK07 Rated) accessory with an optical lens providing a 110°
distribution
• CCT Switchable between 3500K, 4000K and 5000K
• Power Switchable: 150W (14,600 – 25,000 lumens) / 255W (32,100 – 42,050 lumens) / 300W (33,600 – 49,000 lumens)
• Switches easily accessible on top of fixture under coin plug cove
• Can be surface or stem/pendant mounted with the use of the surface mount kits (NHBL-SMK-SM, NHBL-SMK-LG; non NSF rated), pendant mount will
require weatherproof junction box and 3/4” downrod provided by others
• cULus Listed for Wet Locations
• NEMA 4X Rated
• NSF Certified for food equipment, rated for Food Zone, Splash Zone
and Non Food Zone
• IP69K Rated
• DesignLights Consortium® (DLC) PREMIUM Qualified (consult QPL
for qualified models)
• Operating temperatures: -40°C to 65°C (-40°F to 149°F)
• Five Year Warranty (Terms and Conditions Apply)
