Description

ShineRetrofits Input:
This EIKO lamp is a DLC-listed 9.9-watt, 4-foot T8 LED Type A glass tube lamp. Delivering 1,800 lumens at 3500K with an 82 CRI, it replaces 32W fluorescent tubes. Featuring a frosted glass lens for optimal heat dissipation and a wide illumination angle, it ensures efficient and even lighting. With a 50,000-hour lifespan and a 5-year limited warranty, it offers long-lasting, reliable performance.

Features:
• LED T8 Type A plug-and-play replacement lamps directly replace T8 fluorescent lamps
 without having to change a ballast
• Functions on most electronic T8 ballast (instant & programmed) and battery backup
• Instantaneous full light output upon power-up
• Wide illumination angle provides up to 330° of light distribution
• Glass material for better light transmission (glass models)
• Plastic (polycarbonate) material for durability and reduced breakage (plastic models)
• Frosted lens reduces visual glare
• Plastic models meet the requirements for NSF; aiding as a component of an NSF lighting
 system
• UL Certified for US & Canada
• FCC Compliant
• RoHS Compliant
• ICES-005 Compliant
• Damp Location
• DesignLights Consortium® Qualified – meets DLC requirements for efficacy and lumen
 maintenance
• High efficacy, up to 194 lm/W
• Available in single CCT models: 3500, 4000 or 5000K
• CRI: >82
• Up to 330° illumination angle. with a beam angle of 210° for glass and 160° for plastic
• Rated Life L70: >50,000 hours
• Input voltage: Ballast dependent
• Power Factor: >0.9
• THD: <20%
• -4°F to 113°F (-20°C to 45°C) operating temperature
• Not recommended for air-tight fixtures
• Available in 2′, 3′, and 4′ lengths
• U-bend models available in 1 5/8″ and 6″ leg spacing
• Frosted glass lens provides optimal heat dissipation (glass models)
• Polycarbonate lens for durability (plastic models)
• G13 base
• 5-Year limited warranty

Applications:
• Office
• Hospital
• Classroom
• Hotel
• Retail
• Warehouse
• Stairwell
• Hallway
• Production
• Gym
• Campus
