Description

Halco 108314 MV400DX 400W MV ED37 MOG PROLUME

Notes:

• It is a characteristic of phosphor-coated vapor lamps to require a few hundred hours of operation to gradually reach normal characteristic color. New lamps may have a slight pink appearance during this initial operation period.

• In general, horizontal lumens will be 5-10% lower than the vertical lumen values.

Warnings:

• Turn power off before inspection, installation, or removal

• Use in fixture designed for use with Mercury Vapor Lamps

• Fixture wattage rating must match the wattage indicated on the outer glass bulb

• Keep combustible materials away from lamp

• Turn power off immediately if glass bulb is broken.Remove and dispose of lamp after it has cooled

• A partial vacuum in the outer bulb may cause glass to fly if the glass is struck

• Do not exceed rated voltage

• Do not use where lamp is directly exposed to water or outdoors without an enclosed fixture

• Do not use lamp if outer glass is scratched or broken

• Use only properly rated ballast

Manufacturer	Halco Lighting
MPN	108314
UPC	807154183142
HTS	8539320040
UNSPSC	39101615
Wattage	400 Watts
Diameter	4.72″ inches
Length (MOL)	10.38″ inches
Energy Star Rated	No
RoHS COMPLIANT (Mercury Free)	Yes
Dimmable	Yes – Dimmable
Lamp Code	MV400DX
Bulb Base	E39
Bulb Base Type	Mogul Screw
Bulb Burning Position	Universal
CCT (Kelvin)	4000K
CCT (Kelvin) Scale
Bulb Shape Type	Elliptical Dimple
Bulb Shape	ED37
Bulb Type	Mercury Vapor
Open Rated	Yes
Lumens	23000
CRI	45
Average Life Hours	24,000 Hours
Master / Inner Carton Quantity	6/1
Osram Equivalent	H33GL-400/DX
Philips Equivalent	H33GL-400DX
Sylvania Equivalent	H33GL-400/DX
Software Upgradeable	No
